5052 aluminum coil
Alloy: 5052
Temper: O/H22/H32/H34/H36/H38
Thickness: 0.3mm to 8.0mm
Width: 500mm to 2600mm,
Minimum thickness: 0.3mm
The magnesium content is between 2.2-2.8%.
Aluminum coil 5052 is Marine grade aluminum coil.
Since it has a very good quality of corrosion resistance, and very good performance of welding, so many customer use this alloy for ship building, like 5052 H32 is always used for small boat building.
Alloy 5052 is the Represents of 5 Series Aluminum-Magnesium Alloy.
5052 h32 aluminum sheet is half hard and temper H32 can allow to make 90 degree bending without cracking. Surface: mill finish surface, bright, polished surface, with blue PVC films or paper-interleaved;
Aluminum sheet 5052 Quality Data Sheet/Characteristics:
| ALLOY | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr | A1 | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5052 | 0.25 | 0.4 | 0.4 | 0.1 | 2.2~2.8 | 0.15~0.35 | — | 0.1 | — | ---- | — | Remainder |
Aluminum Sheet 5052 H32 H34 Mechanical Properties Standard
| Temper | Anti –tensile strength N/m㎡ | Elongation rate（%） | Dimension Control | surface | Hardness | |
|---|---|---|---|---|---|---|
| 5052 H32 | 230Mpa | 12 | Qualified | Mill finish | Above 60HB | |
| 5052 H34 | 260Mpa | 10 | Qualified | Mill finish | Above 68HB |
How to Pack and ship the aluminum sheet 5052?
1.Packing: Strong wooden pallet, with blue PVC films or paper-interleaved,
2.Max Gross weight skid 2500KGS;
3.For 1 x 20FCL can load 20 to 25 Tons max, the same as following pictures.
4.Surface: mill finish with blue PE films to protect the surface.
The aluminum sheet price changes everyday and it depends on the market.
Here is our aluminum sheet price per KGS for you:
| ALLOY | Thickness | FOB Price USD/KGS | Produce time | MOQ | Standard Size | 1 x20FCL | |
|---|---|---|---|---|---|---|---|
| 5052 H32 | 1mm to 6mm | 2.36USD/KGS | 20 Days | 3 TONS | 4’ x 8’ | 25 Tons | |
| 5052 H34 | |||||||
| 5052 O | |||||||
| 5052 H112 | 6mm to 300mm | 2.44USD/KGS |
